Drive-in Racking

Drive-in Racking DC92

Product name

Drive-in Racking DC92

Color

Customized

Material

Q235 steel

Usage

Warehouse Storage, Factory,

Logistics, Industrial and so on

Certification

ISO9001/CE/ISO/TUV

Size

Customized

Structure

Assembled Freely

Height

1350mm - 12000mm, Customized

Capacity

Max. 20000kgs/bay

Width

900mm - 1500mm, Customized

Thickness

1.5mm - 3.0mm

Style

Drive In Rack

Packing

Export Package

Brand

Dachang Racking & Shelving

Port

Foshan/Guangzhou/Shenzhen

How to use the drive-in rack correctly?

The drive-in racking have been put into use by many large enterprises, and it can also be seen that the drive-in shelves bring high economic benefits to enterprises. Then we pay attention not only to this item, but also to How to better use drive-in racks to maximize economic benefits. So how do we correctly use the drive-in racking of Dachang Racking & Shelving model DC92?

1. In order to better use the drive-in rack, it should be noted that when designing a new warehouse or transforming an existing warehouse, it is necessary to review and study the system characteristics applied in the warehouse. To achieve the maximum storage capacity in the smallest space on the shelf, it is necessary to choose a reasonable and economical logistics solution.

2. When using drive-in racks, it is necessary to load and unload goods from one side. This mode of accessing goods can effectively improve time efficiency and work efficiency.

3. The drive-in shelf is a continuous whole shelf that is not divided by aisles, so it needs to be stored on the support rails, the trays are stored in the depth direction, and need to be stored tightly, which can make high-density storage possible.

4. The through-type shelves can be divided into one-way and two-way arrangements according to the picking direction. The total depth of the one-way (wall area) shelves is best controlled within 6 pallet depths, and the two-way (the middle area can be picked up on both sides) The total shelf area It is best to control the depth within 12 pallets in order to improve the efficiency and reliability of forklift access (in this type of racking system, the forklift is a continuous "lifting and hitting" operation method, the forklift is easy to shake and hit the rack, so the stability sufficiency of consideration is crucial).

5. For drive-in racks, the stability of its storage system is weak, so the racks should not be too high, usually need to be controlled within 10 meters, and in order to strengthen the stability of the entire racking system, in addition to specifications, selection should be larger. In addition to some, a tensioning device must be added.

6. When using the drive-in rack, the single pallet should not be too large or heavy, and the weight can generally be controlled within 1500kgs, and the pallet span should not be greater than 1.5 meters. The often equipped forklift is a forward-moving battery forklift or a counterweight. battery forklift.

7. Drive-in racks have extremely high stability requirements due to the dense storage of goods. For this, relatively many rack accessories are required. Generally speaking, the accessories are connected with the rack column pieces, so that the goods can be safely and intensively connected. Store on corbel beams to maximize space.
